DDZ9678 - DDZ9717
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Forward Voltage @ I
F
= 10mA
V
F
0.9 V
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 7)
P
D
500 mW
Thermal Resistance, Junction to Ambient Air (Note 7)
R
θJA
305 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Type
Number
Type
Code
Zener Voltage Range (Note 8)
Maximum Reverse
Leakage Current (Note 9)
V
Z
@ I
ZT
I
ZT
I
R
@ V
R
Nom (V)
Min (V)
Max (V)
µA
µA
V
DDZ9678 D1 1.8 1.71 1.89 50
7.5
1
DDZ9681 (Note 10)
H9
2.4
2.28
2.52
50
2
1
DDZ9682 (Note 10)
HA
2.7
2.565
2.835
50
1
1
DDZ9683 HB 3.0 2.85 3.15 50
0.8
1
DDZ9684 (Note 10)
HC
3.3
3.13
3.47
50
7.5
1.5
DDZ9685 (Note 10)
HD
3.6
3.42
3.78
50
7.5
2
DDZ9686 (Note 10)
HE
3.9
3.70
4.10
50
5
2
DDZ9687 (Note 10)
HF
4.3
4.09
4.52
50
4
2
DDZ9688 (Note 10)
HG
4.7
4.47
4.94
50
5
3
DDZ9689 (Note 10)
HH
5.1
4.85
5.36
50
5
3
DDZ9690 (Note 10)
HJ
5.6
5.32
5.88
50
2
4
DDZ9691 HK 6.2 5.89 6.51 50
1
5
DDZ9692 HL 6.8 6.46 7.14 50
0.1
5.1
DDZ9693 (Note 10)
HM
7.5
7.13
7.88
50
0.1
5.7
DDZ9694 (Note 10)
HN
8.2
7.79
8.61
50
0.1
6.2
DDZ9696 (Note 10)
HP
9.1
8.65
9.56
50
0.1
6.9
DDZ9697 (Note 10)
HQ
10
9.50
10.50
50
0.1
7.6
DDZ9698 HR 11 10.45 11.55 50
0.05 8.4
DDZ9699 (Note 10)
HS
12
11.40
12.60
50
0.05
9.1
DDZ9700 (Note 10)
HT
13
12.35
13.65
50
0.05
9.8
DDZ9701 (Note 10)
HU
14
13.30
14.70
50
0.05
10.6
DDZ9702 HV 15 14.25 15.75 50 0.05 11.4
DDZ9703 HW 16 15.20 16.80 50
0.05 12.1
DDZ9704 (Note 10)
H8
17
16.15
17.85
50
0.05
12.9
DDZ9705 HY 18 17.10 18.90 50 0.05 13.6
DDZ9707 MD 20 19.00 21.00 50
0.05 15.2
DDZ9708 ME 22 20.90 23.10 50
0.05 16.7
DDZ9709 MF 24 22.80 25.20 50
0.05 18.2
DDZ9711 MH 27 25.65 28.35 50
0.05 20.4
DDZ9712 MJ 28 26.60 29.40 50 0.05 21.2
DDZ9713 MK 30 28.50 31.50 50
0.05 22.8
DDZ9714 ML 33 31.35 34.65 50 0.05 25.0
DDZ9715 MM 36 34.20 37.80 50
0.05 27.3
DDZ9716 MN 39 37.05 40.95 50
0.05 29.6
DDZ9717 MO 43 40.85 45.15 50
0.05 32.6
Notes:
7. Device mounted on ceramic PCB = 7.6mm x 9.4mm x 0.87mm with pad areas 25mm
2
at T
A
= +25°C or mounted on FR-5 = 3.5x1.5 inches with
recommended pad layout, which can be found on our website att T
L
= +75°C.
8. Nominal Zener voltage is measured with the device junction in thermal equilibrium at T
T
= +30°C ±1°C.
9. Short duration pulse test used to minimize self-heating effect.
10. Qualified to AEC-Q101 Standards for High Reliability. Please contact the Diodes, Inc. sales department for assistance in ordering any products
expected to meet automotive requirements.
