HD01 – HD06
Maximum Ratings
@T A = 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic Symbol HD01 HD02 HD04 HD06 Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RMM
V
RWM
V
DC
100 200 400 600 V
RMS Reverse Voltage V
RMS
70 140 280 420 V
Average Forward Rectified Current (Note 3) @T A = 40
°C I
O
0.8 A
Non-Repetitive Peak Forward Surge Current, 8.3 ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
30 A
Thermal Characteristics
Characteristic Symbol Value Unit
Typical Thermal Resistance, Junction to Ambient (Note 3) R θJA 75 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Instantaneous Voltage Drop @ 0.4A (per element) V
F
1.0 V
Peak Reverse Current at Rated @T
A
= 25
°C
DC Blocking Voltage (per element) @T
A
= 125 °C
I
R
5.0
500
μA
Typical Total Capacitance (per element) (Note 4) C
T
10 pF
Notes: 3. Mounted on PC Board.
4. Measured at 1.0 MHz and applied reverse voltage of 4.0V.
0
0.2
0.4
0.6
0.8
0 40 80 120 160
I,
A
V
E
R
A
G
E
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F(
A
V
)
T , AMBIENT TEMPERATURE ( C)
Fig. 1 Output Current Derating Curve
A
°
0.01
0.1
1.0
10
0.2 0.6 1.0 1.4
I
, INS
T
AN
T
ANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics (per element)
F
0.4 0.8 1.2 1.6
