Page 3
MBR2045CTP
Document number: DS31799 Rev. 5 - 2
3 of 4
June 2011
© Diodes Incorporated
MBR2045CTP
NEW PROD
UC
T
0.01
0.1
1
10
100
1,000
10,000
100,000
0
5
10
15
20
25
30
35
40
45
I,
I
N
S
T
AN
T
ANE
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(µ
A
)
R
Fig. 3 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
100
1,000
10,000
0.1
1
10
100
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (p
F
)
T
Fig. 4 Total Capacitance vs. Reverse Voltage
V , DC REVERSE VOLTAGE (V)
R
Fig. 5 Forward Current Derating Curve
0
5
10
15
20
0
25
50
75
100
125
150
T , AMBIENT TEMPERATURE (°C)
A
I
, A
VERAGE
F
O
R
W
ARD
CURR
ENT
(A)
F(A
V
)
R
= R
Total Device
θ
θ
JA
JC
R
= 21°C/W
Per Element
Note 3
θJA
0
9
18
27
36
45
Fig. 6 Operating Temperature Derating
V , DC REVERSE VOLTAGE (V)
R
0
25
50
75
100
125
150
T
, DE
R
A
T
E
D
AM
BI
E
N
T
T
EM
P
E
R
A
T
U
R
E (
°C
)
A
Package Outline Dimensions
ITO-220S
DIM.
MIN. MAX. TYP.
A
4.52 4.62 4.57
A1
1.17 1.39
−
A2
2.57 2.77 2.67
b
0.72 0.95 0.84
b2
1.15 1.54 1.26
c
0.356
0.61
−
D
14.22 16.51 15.00
D1
8.60 8.80 8.70
D2 13.68 14.08
−
e
2.49 2.59 2.54
e1
4.98 5.18 5.08
E
10.01 10.21 10.11
E1
6.86 8.89
−
H1
5.85 6.85
−
L
13.30 13.90 13.60
L1
−
6.35
−
P
3.54 4.08
−
Q
2.54 3.42
−
All Dimensions in mm
E
D1
L
b2
b
e
A2
+
A
D
7 Ref
°
5 Ref
°
+
D2
H1
E1
5 Ref
°
A1
c
e1
Q
ØP
1.7 Ref
5 Ref
°
5 Ref
°
L1
Ø1.5
Dp 0.1 max
