Data Sheet

HIGH VOLTAGE POWER SCHOTTKY RECTIFIER MBR2150

Aug. 2011 Rev. 1. 2 BCD Semiconductor Manufacturing Limited

5

Mechanical Dimensions

DO-214AC Unit: mm(inch)

3. 990(0. 157)
4. 600(0. 181)

4. 800(0. 189)
5. 280(0. 208)

0. 760(0. 030)
1. 520(0. 060)

1. 900(0. 075)

2. 290(0. 090)

0. 100(0. 004)
0. 310(0. 012)

0. 152(0. 006)
0. 305(0. 012)

Cathode line by

marking
