Diodes MBRB1530CT - MBRB1545CT - Manual (Page 3)

MBRB1530CT - MBRB1545CT
Document number: DS13015 Rev. 7 - 2
3 of 4
www.diodes.com
May 2011
© Diodes Incorporated
MBRB1530CT - MBRB1545CT
50
100
150
0
200
250
300
1 10 100
I,
P
EAK
F
O
R
WA
R
D S
U
R
G
E
C
U
R
R
EN
T
(A
)
FS
M
NUMBER OF CYCLES AT 60 Hz
Fig. 3 Max Non-Repetitive Surge Current
8.3 ms single half-sine-wave
10
100
1,000
0.1 1.0 10 100
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance
R
T = 25°C
f = 1MHz
j
0.01
0.1
1.0
10
100
0 40 80 120
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
R
EV
E
R
SE
C
U
R
R
E
N
T
(m
A
)
R
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics, per element
Package Outline Dimensions
D 2 PAK
Dim Min Max
A 4.07 4.82
b 0.51 0.99
b1 1.15 1.77
c 0.356 0.58
c1 1.143 1.65
D 8.39 9.65
E 9.66 10.66
e 2.54 Typ
H 14.61 15.87
L 1.78 2.79
L1 ⎯ 1.67
L2 ⎯ 1.77
a 0° 8°
All Dimensions in mm
E
b1
c
H
D
L1
b
L2
L c1
A
e
a
1 2 K
