MBR10100
Document number: DS31412 Rev. 11 - 2
2 of 4
April 2011
© Diodes Incorporated
MBR10100CTP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current
(Per Leg)
I
O
5
A
(Total)
10
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
100 A
Isolation Voltage
From Terminal Heatsink t = 1 min.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Case
R
θJC
3
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- 0.79
0.85
V
I
F
= 5A, T
J
= 25ºC
- 0.65
0.75
I
F
= 5A, T
J
= 125ºC
Leakage Current (Note 3)
I
R
- -
0.1
mA
V
R
= 100V, T
J
= 25ºC
- - 15
V
R
= 100V, T
J
= 125ºC
Notes:
3. Short duration pulse test used to minimize self-heating effect.
Fig. 1 Typical Forward Characteristics
0.01
0.1
1
10
100
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
I
, INST
A
N
T
A
NEOUS
F
O
R
W
ARD CURR
ENT
(
A
)
F
0
200
400
600
800
1,000 1,200 1,400
T = 25°C
A
T = -55°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
I
, IN
ST
ANT
A
NEOU
S
REV
E
RSE
CURRENT
(
µ
A)
R
0.01
0.1
1
10
100
1,000
10,000
0
20
40
60
80
100
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
