MBR20100CT / MBRF20100CT
Document number: DS36343 Rev. 8 - 2
3 of 4
www.diodes.com
November 2013
© Diodes Incorporated
MBR20100CT / MBRF20100CT
ADVANCED INFORMATION
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
I
, I
N
ST
ANT
A
N
E
OUS RE
VERSE
CURRE
NT
(
m
A
)
R
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Figure 3 Typical Reverse Characteristics
10
0 20 40 60 80 100
1
0.1
0.001
0.0001
0.00001
0.01
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = 175°C
A
T , AMBIENT TEMPERATURE (°C)
A
Figure 4 Forward Current Derating Curve
I,
A
V
E
R
A
G
E F
O
R
WA
R
D
C
U
R
R
EN
T (
A
)
F(
A
V
)
Note 5
0.0
2.0
4.0
6.0
8.0
10.0
12.0
0 25 50 75 100 125 150 175
TO220AB
Dim Min Typ Max
A 3.56 - 4.82
A1 0.51 - 1.39
A2 2.04 - 2.92
b 0.39 0.81 1.01
b2 1.15 1.24 1.77
c 0.356 - 0.61
D 14.22 - 16.51
D1 8.39 - 9.01
e 2.54
e1 5.08
E 9.66 - 10.66
H1 5.85 - 6.85
L 12.70 - 14.73
L1 - - 6.35
P 3.54 - 4.08
Q 2.54 - 3.42
All Dimensions in mm
ITO220AB
Alternate
Dim Min Max
A 4.36 4.77
A1 2.54 3.10
A2 2.54 2.80
b 0.55 0.75
b1 1.20 1.50
c 0.38 0.68
D 14.50 15.50
D1 8.38 8.89
e 2.41 2.67
E 9.72 10.27
L 9.87 10.67
L1 15.8 17.00
P 3.08 3.39
Q 2.60 3.00
All Dimensions in mm
A
A1
c
D
E
L
b
e1
b2
P
H1
Q
L1
A2
e
S
E
A
T
IN
G
PLAN
E
D1
16
.0
0
0.20*

*Guaranteed by TO-220AB leadframe design
A
A1
D1
A2
c
e
b
b1
L
L1
D
Q
E Ø P
