Diodes DFLS1100 - Manual (Page 4)

DFLS1100
Document number: DS30497 Rev. 11 - 2
4 of 5
www.diodes.com
September 2013
© Diodes Incorporated
DFLS1100
POWERDI is a registered trademark of Diodes Incorporated.
E C
A
B
D
H
L 2
L L 1
L 3
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
0
20
40
60
80
100
120
0 25 50 75 100 125 150 175
T , JUNCTION TEMPERATURE ( C)
J
°
P
,
A
V
A
L
A
NCHE PEAK
PUL
SE P
O
W
E
R
D
E
RA
T
ING IN
PE
RCE
NT
AGE
(
%
)
AR
M
Fig. 7 Pulse Derating Curve
POWERDI
®
123
Dim Min Max Typ
A 3.50 3.90 3.70
B 2.60 3.00 2.80
C 1.63 1.93 1.78
D 0.93 1.00 0.98
E 0.85 1.25 1.00
H 0.15 0.25 0.20
L 0.40 0.50 0.45
L1 1.25 1.40 1.35
L2 1.025 1.125 1.10
L3 0.125 0.275 0.20
All Dimensions in mm
POWERDI
®
123
Dim Min Max Typ
A 3.50 3.90 3.70
B 2.60 3.00 2.80
C 1.63 1.93 1.78
D 0.93 1.00 0.98
E 0.85 1.25 1.00
H 0.15 0.25 0.20
L 0.40 0.50 0.45
L1 1.25 1.40 1.35
L2 1.025 1.125 1.10
L3 0.125 0.275 0.20
All Dimensions in mm
