Diodes 74LVCE1G08 User Manual
Page 9
74LVCE1G08
SINGLE 2 INPUT POSITIVE AND GATE
74LVCE1G08
Document number: DS32213 Rev. 2 - 2
9 of 14
December 2010
© Diodes Incorporated
NEW PROD
UC
T
Ordering Information
Device
Package
Code
Packaging
(Note 5)
7” Tape and Reel
Quantity
Part Number Suffix
74LVCE1G08W5-7
W6
SOT25
3000/Tape & Reel
-7
74LVCE1G08SE-7
SE
SOT353
3000/Tape & Reel
-7
74LVCE1G08FZ4-7
FZ4
DFN1410
5000/Tape & Reel
-7
Note: 6. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
