74LVC1G57
CONFIGURABLE MULTIPLE-FUNCTION GATE
74LVC1G57
Document number: DS35125 Rev. 4 - 2
9 of 15
June 2012
© Diodes Incorporated
NEW PROD
UC
T
Ordering Information
W6 : SOT26
DW : SOT363
FW4 : X2-DFN1010-6
FZ4 : X2-DFN1410-6
74 LVC1G 57 XXX - 7
Function
Package
7 : Tape & Reel
Packing
Logic Device
74 : Logic Prefix
LVC : 1.65 to 5.5V
Family
1G : One gate
57 : 3-Input
Configurable
Multiple-Function
Gate
Device
Package Code
Packaging
(Note 7)
7” Tape and Reel
Quantity
Part Number Suffix
74LVC1G57W6-7
W6
SOT26
3000/Tape & Reel
-7
74LVC1G57DW-7
DW
SOT363
3000/Tape & Reel
-7
74LVC1G57FW4-7
FW4
X2-DFN1010-6
5000/Tape & Reel
-7
74LVC1G57FZ4-7
FZ4
X2-DFN1410-6
5000/Tape & Reel
-7
