74LVC1G57
CONFIGURABLE MULTIPLE-FUNCTION GATE
74LVC1G57
Document number: DS35125 Rev. 4 - 2
4 of 15
June 2012
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings
(Note 4)
Symbol
Description
Rating
Unit
ESD HBM
Human Body Model ESD Protection
2
KV
ESD MM
Machine Model ESD Protection
200
V
V
CC
Supply Voltage Range
-0.5 to +6.5
V
V
I
Input Voltage Range
-0.5 to +6.5
V
V
O
Voltage applied to output in high impedance or I
OFF
state
-0.5 to +6.5
V
V
O
Voltage applied to output in high or low state
-0.3 to V
CC
+0.5
V
I
IK
Input Clamp Current V
I
<0
-50 mA
I
OK
Output Clamp Current
-50
mA
I
O
Continuous output current
±50
mA
Continuous current through Vdd or GND
±100
mA
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
Notes: 4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device
operation should be within recommend values.
Recommended Operating Conditions
(Note 5)
Symbol
Parameter
Min
Max
Unit
V
CC
Operating Voltage
Operating 1.65
5.5
V
Data retention only
1.5
V
V
I
Input Voltage
0 5.5
V
V
O
Output Voltage
0
V
CC
V
I
OH
High-level output current
V
CC
= 1.65V
-4
mA
V
CC
= 2.3V
-8
V
CC
= 3V
-16
-24
V
CC
= 4.5V
-32
I
OL
Low-level output current
V
CC
= 1.65V
4
mA
V
CC
= 2.3V
8
V
CC
= 3V
16
24
V
CC
= 4.5V
32
Δt/ΔV
Input transition rise or fall rate
V
CC
= 1.8V ± 0.15V, 2.5V ± 0.2V
20
ns/V
V
CC
= 3.3V ± 0.3V
10
V
CC
= 5V ± 0.5V
5
T
A
Operating free-air temperature
-40
+125
ºC
Notes: 5. Unused inputs should be held at V
CC
or Ground.
