Electrical characteristics – Diodes 74AUP1G14 User Manual
Page 5
74AUP1G14
Document number: DS35152 Rev. 2 - 2
5 of 14
July 2013
© Diodes Incorporated
74AUP1G14
Electrical Characteristics
(cont.) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Test
Conditions
V
CC
T
A
= -40 to +125
o
C
Unit
Min Max
V
T+
Positive-going
input threshold
voltage
0.8V
0.4
0.65
V
1.1V 0.53 0.9
1.4V 0.74 1.11
1.65V 0.91 1.29
2.3V 1.37 1.77
3.0V 1.61 2.32
V
T-
Negative-going
input threshold
voltage
0.8V
0.15
0.4
V
1.1V 0.26 0.65
1.4V 0.39 0.75
1.65V 0.47 0.84
2.3V 0.69 1.04
3.0V 0.88 1.24
ΔV
T
Hysteresis
(V
T+
-
V
T-)
0.8V
0.07
0.5
V
1.1V 0.08 0.46
1.4V 0.18 0.56
1.65V 0.27 0.66
2.3V 0.53 0.92
3.0V 0.79 1.31
V
OH
High-Level
Output Voltage
I
OH
= -20
μA
0.8V to 3.6V
V
CC
– 0.11
V
I
OH
= -1.1mA
1.1V
0.6 X V
CC
I
OH
= -1.7mA
1.4V 0.93
I
OH
= -1.9mA
1.65V 1.17
I
OH
= -2.3mA
2.3V
1.77
I
OH
= -3.1mA
1.67
I
OH
= -2.7mA
3V
2.40
I
OH
= -4mA
2.30
V
OL
Low-Level Output
Voltage
I
OL
= 20
μA
0.8V to 3.6V
0.11
V
I
OL
= 1.1mA
1.1V
0.33 X V
CC
I
OL
= 1.7mA
1.4V 0.41
I
OL
= 1.9mA
1.65V 0.39
I
OL
= 2.3mA
2.3V
0.36
I
OL
= 3.1mA
0.50
I
OL
= 2.7mA
3V
0.36
I
OL
= 4mA
0.50
I
I
Input Current
V
I
= GND to 3.6V
0V to 3.6V
± 0.75
μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V
0
±
3.5
μA
ΔI
OFF
Delta Power
Down Leakage
Current
V
I
or V
O
= 0V to 3.6V
0V to 0.2V
± 2.5
μA
I
CC
Supply Current
V
I
= GND or V
CC
, I
O
= 0
0.8V to 3.6V
3.0
μA
ΔI
CC
Additional Supply
Current
Input at V
CC
-0.6V
3.3V 75
μA
