74AUP1G14
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Test
Conditions
V
CC
T
A
= +25°C
T
A
= -40°C to +85°C
Unit
Min Max Min Max
V
T+
Positive-going
input threshold
voltage
0.8V
0.4
0.65
0.4
0.65
V
1.1V 0.53 0.9 0.53 0.9
1.4V 0.74 1.11 0.74 1.11
1.65V 0.91 1.29 0.91 1.29
2.3V 1.37 1.77 1.37 1.77
3.0V 1.61 2.32 1.61 2.32
V
T-
Negative-going
input threshold
voltage
0.8V
0.15
0.4
0.15
0.4
V
1.1V 0.26 0.65 0.26 0.65
1.4V 0.39 0.75 0.39 0.75
1.65V 0.47 0.84 0.47 0.84
2.3V 0.69 1.04 0.69 1.04
3.0V 0.88 1.24 0.88 1.24
ΔV
T
Hysteresis
(V
T+
-
V
T-)
0.8V
0.07
0.5
0.07
0.5
V
1.1V 0.08 0.46 0.08 0.46
1.4V 0.18 0.56 0.18 0.56
1.65V 0.27 0.66 0.27 0.66
2.3V 0.53 0.92 0.53 0.92
3.0V 0.79 1.31 0.79 1.31
V
OH
High-Level Output
Voltage
I
OH
= -20
μA
0.8V to 3.6 V
V
CC
– 0.1
V
CC
– 0.1
V
I
OH
= -1.1mA
1.1V
0.75 X V
CC
0.7 X V
CC
I
OH
= -1.7mA
1.4V
1.11 1.03
I
OH
= -1.9mA
1.65V
1.32 1.30
I
OH
= -2.3mA
2.3V
2.05 1.97
I
OH
= -3.1mA
1.9 1.85
I
OH
= -2.7mA
3V
2.72 2.67
I
OH
= -4mA
2.6 2.55
V
OL
Low-Level Output
Voltage
I
OL
= 20
μA
0.8V to 3.6V
0.1
0.1
V
I
OL
= 1.1mA
1.1V
0.3 X V
CC
0.3 X V
CC
I
OL
= 1.7mA
1.4V 0.31 0.37
I
OL
= 1.9mA
1.65V 0.31 0.35
I
OL
= 2.3mA
2.3V
0.31 0.33
I
OL
= 3.1mA
0.44 0.45
I
OL
= 2.7mA
3V
0.31 0.33
I
OL
= 4 mA
0.44 0.45
I
I
Input Current
V
I
= GND to 3.6V
0V to 3.6V
± 0.1
± 0.5
μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V
0
±
0.2
0.6
μA
ΔI
OFF
Delta Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V
0V to 0.2V
± 0.2
0.6
μA
I
CC
Supply Current
V
I
= GND or V
CC
, I
O
= 0
0.8V to 3.6V
0.5
0.9
μA
ΔI
CC
Additional Supply
Current
Input at V
CC
–0.6V
3.3V
40 50
μA
