74AHC1G126
SINGLE BUFFER GATE WITH 3-STATE OUTPUT
74AHC1G126
Document number: DS35177 Rev. 1 - 2
5 of 9
March 2011
© Diodes Incorporated
NEW PROD
UC
T
Switching Characteristics
V
CC
= 3.3V ± 0.3
(see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
25ºC
-40ºC to 85ºC
-40ºC to 125ºC
Unit
Min
Typ.
Max
Min
Max
Min
Max
t
pd
A
Y
C
L
=15pF
0.6 4.4 8.0 0.6 9.5 0.6 10.0
ns
C
L
=50pF
0.6 6.3 11.5 0.6 13.0 0.6 14.5
ns
t
en
OE Y
C
L
=15pF
0.6 4.9 8.0 0.6 9.5 0.6 10.0
ns
C
L
=50pF
0.6 7.0 11.5 0.6 13.0 0.6 14.5
ns
t
dis
OE
Y
C
L
=15pF
0.6 6.3 9.7 0.6 11.5 0.6 12.5
ns
C
L
=50pF
0.6 9.0 13.2 0.6 15.0 0.6 16.5
ns
V
CC
= 5V ± 0.5V
(see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
25ºC
-40 ºC to 85 ºC
-40 ºC to 125 ºC
Unit
Min
Typ.
Max
Min
Max
Min
Max
t
pd
A
Y
C
L
=15pF
0.6 3.4 5.5 0.6 6.5 0.6 7.0
ns
C
L
=50pF
0.6 4.7 7.5 0.6 8.5 0.6 9.5
ns
t
en
OE Y
C
L
=15pF
0.6 3.6 5.6 0.6 6.3 0.6 7.0
ns
C
L
=50pF
0.6 5.4 8.0 0.6 9.0 0.6 9.5
ns
t
dis
OE Y
C
L
=15pF
0.6 4.3 6.8 0.6 8.0 0.6 8.5
ns
C
L
=50pF
0.6 6.1 8.8 0.6 10.0 0.6 11.0
ns
Operating Characteristics
T
A
= 25 ºC
Parameter
Test
Conditions
V
CC
= 5 V
Unit
Typ.
C
pd
Power dissipation capacitance
f = 1 MHz
No Load
12
pF
