Switching Characteristics
V
CC
= 3.3V ±0.3 (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
+25°C
-40°C to +85°C
-40°C to +125°C
Unit
Min Typ Max Min
Max
Min
Max
t
pd
A or B
Y
C
L
= 15pF
0.6 4.6 7.5 0.6 8.5 0.6 9.0
ns
C
L
= 50pF
0.6 6.5 11.0 0.6 12.0 0.6 12.5
ns
V
CC
= 5V ±0.5V (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
+25°C
-40°C to +85°C
-40°C to +125°C
Unit
Min Typ Max Min
Max
Min
Max
t
pd
A or B
Y
C
L
= 15pF
0.6 3.2 5.5 0.6 6.5 0.6 7.0
ns
C
L
= 50pF
0.6 4.6 7.5 0.6 8.0 0.6 8.5
ns
Operating Characteristics
T
A
= +25°C
Parameter
Test
Conditions
V
CC
= 5V
Unit
Typ
C
pd
Power dissipation capacitance
f = 1 MHz
No Load
5
pF
Parameter Measurement Information
R
L
C
L
(see Note A)
From Output
Under Test
V
LOAD
TEST Condition
t
PLZ
(see Notes D and E)
t
PZL
(see Notes D and F)
V
LOAD
V
LOAD
V
CC
Inputs
V
M
V
LOAD
C
L
R
L
V∆
V
I
t
r
/t
f
3.3V ±0.3V
V
CC
≤3ns
V
CC
/2 V
CC
15pF 1KΩ 0.3V
3.3V ±0.3V
V
CC
≤3ns
V
CC
/2 V
CC
50pF 1KΩ
0.3V
5V ±0.5V
V
CC
≤3ns
V
CC
/2
V
CC
15pF 1KΩ
0.3V
5V ±0.5V
V
CC
≤3ns
V
CC
/2 V
CC
50pF 1KΩ
0.3V
