Switching Characteristics
Symbol Parameter
Test
Conditions
V
CC
T
A
= +25°C -40°C to +85°C -40°C to +125°C
Unit
Min Typ Max Min Max Min Max
t
PD
Propagation
Delay A
N
to Y
N
Figure 1
C
L
= 15pF
2.5V ± 0.2V — 7.1 12.8 1 15 1 16
ns 3.3V ± 0.3V — 5 7.9 1 9.5 1 9.5
5.0V ± 0.5V — 3.6 5.5 1 6.5 1 6.5
Figure 1
C
L
= 50pF
2.5V ± 0.2V — 9.6 16.2 1 19 1 20
ns 3.3V ± 0.3V — 6.9 11.4 1 13 1 13
5.0V ± 0.5V — 4.9 7.5 1 8.5 1 8.5
Operating Characteristics
T
A
= +25°C
Parameter Test
Conditions
V
CC
Typ Unit
C
pd
Power Dissipation
Capacitance per Gate
f = 10MHz
C
L
= 50pF
3.3V 9.5
pF
5.0V 11.5
Noise Characteristics
V
CC
= 3V, C
L
= 50pF, T
A
= +25°C
Symbol Parameter Min Typ Max Unit
V
OL(p)
Quiet output, maximum dynamic V
OL
– 0.2 0.8 V
V
OL(V)
Quiet output, minimum dynamic V
OL
– -0.1 -0.8 V
V
OH(V)
Quiet output, minimum dynamic V
OH
– 3.1 – V
V
IH(D)
High Level dynamic input voltage 2.31 – – V
V
IL(D)
Low Level dynamic input voltage – – 0.99 V
Package Characteristics
Symbol Parameter Test Conditions V
CC
Min Typ Max Unit
C
i
Input Capacitance V
i
= V
CC
– or GND 2.0 to 5.5V — 3.3 10 pF
