74HCU04
Parameter Measurement Information
V
CC
Inputs
V
M
C
L V
I
t
r
/t
f
2.0V to 6.0V V
CC
6ns V
CC
/2 15pF, 50pF
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Notes: A Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 1 MHz.
C. Inputs are measured separately one transition per measurement.
D. t
PLH
and t
PHL
are the same as t
PD
.
Figure 1 Load Circuit and Voltage Waveforms
