74HC595
Absolute Maximum Ratings
(Note 4)
(@T
A
= +25°C, unless otherwise specified.)
Symbol
Description
Rating
Unit
ESD HBM
Human Body Model ESD Protection
2
kV
ESD CDM
Charged Device Model ESD Protection
1
kV
ESD MM
Machine Model ESD Protection
200
V
V
CC
Supply Voltage Range
-0.5 to +7.0
V
V
I
Input Voltage Range
-0.5 to +7.0
V
V
o
Voltage applied to output in high or low state
-0.3 to V
CC
+0.5
V
I
IK
Input Clamp Current V
I
< -0.5V
-20 mA
I
IK
Input Clamp Current VI > Vcc +0.5V
20
mA
I
OK
Output Clamp Current V
O
<-0.5V
-20 mA
I
OK
Output Clamp Current V
O
> V
CC
+0.5V
20 mA
I
O
Continuous output current
Q7 standard output
±25
mA
Qn bus driver outputs
±35
mA
I
CC
Continuous current through Vdd or GND
70
mA
I
GND
Continuous current through Vdd or GND
-70
mA
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
P
TOT
Total Power Dissipation
500
mW
Note:
4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be
within recommend values.
Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Max Unit
V
CC
Supply Voltage
2.0 6.0
V
V
I
Input Voltage
0
V
CC
V
V
O
Output Voltage
Active Mode
0
V
CC
V
Δt/ΔV
Input transition rise or fall rate
V
CC
= 2.0V
1000
ns/V
V
CC
= 4.5V
500
V
CC
= 6.0V
400
T
A
Operating free-air temperature
-40 +125 °C
Note:
5. Unused inputs should be held at V
CC
or Ground.
