Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions V
CC
T
A
= +25°C T
A
=-40 to +85°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
— 0.8V to 1.65V 0.80 X V
CC
— 0.80 X V
CC
—
V
— 1.65V to 1.95V 0.65 X V
CC
— 0.65 X V
CC
—
— 2.3V to 2.7V 1.6 — 1.6 —
— 3.0V to 3.6V 2.0 — 2.0 —
V
IL
Low-Level Input
Voltage
— 0.8V to 1.65V — 0.30 X V
CC
— 0.30 X V
CC
V
— 1.65V to 1.95V — 0.35 X V
CC
— 0.35 X V
CC
— 2.3V to 2.7V — 0.7 — 0.7
— 3.0V to 3.6V — 0.9 — 0.9
V
OH
High-Level
Output Voltage
I
OH
= -20μA 0.8V to 3.6V V
CC
– 0.1 — V
CC
– 0.1 —
V
I
OH
= -1.1mA 1.1V 0.75 X V
CC
— 0.7 X V
CC
—
I
OH
= -1.7mA 1.4V 1.11 — 1.03 —
I
OH
= -1.9mA 1.65V 1.32 — 1.3 —
I
OH
= -2.3mA
2.3V
2.05 — 1.97 —
I
OH
= -3.1mA 1.9 — 1.85 —
I
OH
= -2.7mA
3V
2.72 — 2.67 —
I
OH
= -4mA 2.6 — 2.55 —
V
OL
Low-Level Input
Voltage
I
OL
= 20μA 0.8V to 3.6V — 0.1 — 0.1
V
I
OL
= 1.1mA 1.1V — 0.3 X V
CC
— 0.3 X V
CC
I
OL
= 1.7mA 1.4V — 0.31 — 0.37
I
OL
= 1.9mA 1.65V — 0.31 — 0.35
I
OL
= 2.3mA
2.3V
— 0.31 — 0.33
I
OL
= 3.1mA — 0.44 — 0.45
I
OL
= 2.7mA
3V
— 0.31 — 0.33
I
OL
= 4mA — 0.44 — 0.45
I
I
Input Current A or B Input 0V to 3.6V — ± 0.1 — ± 0.5 μA
I
OFF
Power Down V
I
or V
O
= 0V to 3.6V 0V — ± 0.2 — ± 0.6 μA
∆I
OFF
Delta Power V
I
or V
O
= 0V to 3.6V 0V to 0.2V — ± 0.2 — ± 0.6 μA
I
CC
Supply Current V
I
= GND or V
CC,
I
O
= 0 0.8V to 3.6V — 0.5 — 0.9 μA
∆I
CC
Additional Supply One input at V
CC
–0.6V Other 3.3V — 40 — 50 μA
