74AUP2G34
Document number: DS35514 Rev. 3 - 2
5 of 11
December 2013
© Diodes Incorporated
ADVANCED INFORMATION
74AUP2G34
Switching Characteristics
C
L
= 5pF see Figure 1
Parameter
From
Input
TO
OUTPUT
V
CC
T
A
= +25°C
T
A
= -40 to +85°C T
A
= -40 to +125°C
Unit
Min Typ Max Min Max Min Max
t
pd
A Y
0.8V — 14.9 — — — — —
ns
1.2V
±
0.1V 2.6 4.7 10.1 2.0 11.1 2.0 12.2
1.5V
±
0.1V 2.1 3.4 5.7 1.6 6.5 1.6 7.2
1.8V
±
0.15V
1.8 2.9 4.5 1.4 5.2 1.4 5.8
2.5V
±
0.2V 1.5 2.3 3.5 1.2 4.2 1.2 4.6
3.3V
±
0.3V 1.4 2.1 3.2 1.0 3.8 1.0 4.2
C
L
= 10pF see Figure 1
Parameter
From
Input
TO
OUTPUT
V
CC
T
A
= +25°C
T
A
= -40 to +85°C T
A
= -40 to +125°C
Unit
Min
Typ
Max
Min
Max
Min
Max
t
pd
A
Y
0.8V
—
18.4
—
—
—
—
—
ns
1.2V ± 0.1V
3.2
5.6
11.8
2.3
12.8
2.3
13.5
1.5V ± 0.1V
2.6
4.1
6.7
1.9
7.7
1.9
8.5
1.8V ± 0.15V
2.3
3.4
5.3
1.7
6.2
1.7
6.9
2.5V ± 0.2V
2.0
2.9
4.2
1.5
5.0
1.5
5.5
3.3V ± 0.3V
1.7
2.6
3.8
1.4
4.6
1.4
5.1
C
L
= 15pF see Figure 1
Parameter
From
Input
TO
OUTPUT
V
CC
T
A
= +25°C
T
A
= -40 to +85°C T
A
= -40 to +125°C
Unit
Min
Typ
Max
Min
Max
Min
Max
t
pd
A
Y
0.8V
—
21.9
—
—
—
—
—
ns
1.2V ± 0.1V
3.6
6.4
13.8
2.6
15.7
2.6
15.9
1.5V ± 0.1V
3.0
4.6
7.6
2.2
8.9
2.2
9.8
1.8V ± 0.15V
2.6
3.9
6.0
2.0
7.2
2.0
7.9
2.5V ± 0.2V
2.3
3.3
4.8
1.8
5.7
1.8
6.3
3.3V ± 0.3V
1.8
3.1
4.2
1.6
5.0
1.6
5.5
C
L
= 30pF see Figure 1
Parameter
From
Input
TO
OUTPUT
V
CC
T
A
= +25°C
T
A
= -40 to +85°C T
A
= -40 to +125°C
Unit
Min Typ Max Min Max Min Max
t
pd
A Y
0.8V — 32.1 — — — — —
ns
1.2V
±
0.1V 4.8 8.7 16.3 3.6 18.9 3.6 20.8
1.5V
±
0.1V 4.0 6.2 10.3 3.4 12.2 3.4 13.4
1.8V
±
0.15V
3.6 5.2 8.1 3.2 9.8 3.2 10.8
2.5V
±
0.2V 2.4 4.4 6.4 2.3 7.7 2.3 8.5
3.3V
±
0.3V 2.2 4.2 5.6 2.1 6.5 2.1 7.2
