74AUP2G34
Document number: DS35514 Rev. 3 - 2
2 of 11
December 2013
© Diodes Incorporated
ADVANCED INFORMATION
74AUP2G34
Pin Descriptions
Pin Name
Pin No.
Function
1A 1
Data
Input
GND 2
Ground
2A 3
Data
Input
2Y 4
Data
Output
V
CC
5 Supply
Voltage
1Y 6
Data
Output
Logic Diagram
Function Table
Inputs
Outputs
A
Y
H H
L L
Absolute Maximum Ratings
(Note 4) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
Rating
Unit
ESD HBM
Human Body Model ESD Protection
2
KV
ESD CDM
Charged Device Model ESD Protection
1
KV
ESD MM
Machine Model ESD Protection
200
V
V
CC
Supply Voltage Range
-0.5 to +4.6
V
V
I
Input Voltage Range
-0.5 to +4.6
V
V
O
Voltage Applied to Output in High or Low State
-0.5 to V
CC
+0.5
V
I
IK
Input Clamp Current V
I
< 0
50
mA
I
OK
Output Clamp Current (V
O
< 0 )
-50 mA
I
O
Continuous Output Current (V
O
= 0 to V
CC
)
±20 mA
I
CC
Continuous Current Through V
CC
50
mA
I
GND
Continuous Current Through GND
-50
mA
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
Note:
4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be
within recommend values.
