Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions V
CC
T
A
= +25°C T
A
= -40 to +85°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
0.8V to 1.65V 0.80 X V
CC
0.80 X V
CC
V
1.65V to 1.95V 0.65 X V
CC
0.65 X V
CC
2.3V to 2.7V 1.6 1.6
3.0V to 3.6V 2.0 2.0
V
IL
Low-Level Input
voltage
0.8V to 1.65V 0.30 X V
CC
0.30 X V
CC
V
1.65V to 1.95V 0.35 X V
CC
0.35 X V
CC
2.3V to 2.7V 0.7 0.7
3.0V to 3.6V 0.9 0.9
V
OL
Low-Level Output
Voltage
I
OL
= 20μA 0.8V to 3.6V 0.1 0.1
V
I
OL
= 1.1mA 1.1V 0.3 X V
CC
0.3 X V
CC
I
OL
= 1.7mA 1.4V 0.31 0.37
I
OL
= 1.9mA 1.65V 0.31 0.35
I
OL
= 2.3mA
2.3V
0.31 0.33
I
OL
= 3.1mA 0.44 0.45
I
OL
= 2.7mA
3V
0.31 0.33
I
OL
= 4mA 0.44 0.45
I
I
Input Current A or B Input, V
I
= GND to 3.6V 0V to 3.6V ±0.1 ±0.5 μA
I
OZ
Z State
Leakage Current
V
O
= 3.6V, V
i
= 3.6V 3.6V ±0.1 ±0.5 μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V 0V ±0.2 ±0.6 μA
∆I
OFF
Delta Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V 0V to 0.2V ±0.2 ±0.6 μA
I
CC
Supply Current V
I
= GND or V
CC
, I
O
= 0 0.8V to 3.6V 0.5 0.9 μA
∆I
CC
Additional Supply
Current One input at V
CC
-0.6V
Other inputs at V
CC
or GND
3.3V 40 50 μA
Symbol Parameter Test Conditions V
CC
T
A
= -40°C to +125°C
Unit
Min Max
V
IH
High-Level Input Voltage
0.8V to 1.65V 0.80 X V
CC
V
1.65V to 1.95V 0.70 X V
CC
2.3V to 2.7V 1.6
3.0V to 3.6V 2.0
V
IL
Low-Level Input voltage
0.8V to 1.65V 0.25 X V
CC
V
1.65V to 1.95V 0.30 X V
CC
2.3V to 2.7V 0.7
3.0V to 3.6V 0.9
V
OL
Low-Level Output Voltage
I
OL
= 20μA 0.8V to 3.6V 0.11
V
I
OL
= 1.1mA 1.1V 0.33 X V
CC
I
OL
= 1.7mA 1.4V 0.41
I
OL
= 1.9mA 1.65V 0.39
I
OL
= 2.3mA
2.3V
0.36
I
OL
= 3.1mA 0.50
I
OL
= 2.7mA
3V
0.36
I
OL
= 4mA 0.50
I
I
Input Current A or B Input, V
I
= GND to 3.6V 0V to 3.6V ± 0.75 μA
I
OZ
Z State
Leakage Current
V
O
= 3.6V, V
i
= 3.6V 3.6V ± 0.75 μA
I
OFF
Power Down Leakage Current V
I
or V
O
= 0V to 3.6V 0V ± 0.75 μA
∆I
OFF
Delta Power Down Leakage
Current
V
I
or V
O
= 0V to 3.6V 0V to 0.2V ± 2.5 μA
I
CC
Supply Current V
I
= GND or V
CC
, I
O
= 0 0.8V to 3.6V 1.4 μA
∆I
CC
Additional Supply Current
Input at V
CC
-0.6V Other inputs
at V
CC
or GND
3.3V 75 μA
