background image


Data Sheet

Enhanced Multi-touch Capacitive Touch Screen Controller AUR3852

Feb. 2013 Rev. 1. 0 BCD Semiconductor Manufacturing Limited

9

Pin Description (Continued)

Pin Number

Pin

Name

Pin

Type

Pin Function

QFN-6×6-

48

QFN-7×7-

56

- 14

P3.3

I/O

Port 3.3 GPIO

8051 P3.3 GPIO

DL13

Left driving line 13

- 22

P3.4

I/O

Port 3.4 GPIO

8051 P3.4 GPIO

DR12

Right driving line 12

- 23

P3.5

I/O

Port 3.5 GPIO

8051 P3.5 GPIO

DR11

Right driving line 11

- 24

P1.4

I/O

Port 1.4 GPIO

8051 P1.4 GPIO

DR10

Right driving line 10

- 55,56

XDX0,

XDX1

I, A

Driving line 26,27
