Suggested Pad Layout
(1) Package Type: SOT-23
Y
G Z
Y
X E
Grid placement courtyard
Dimensions
Z
(mm)/(inch)
G
(mm)/(inch)
X
(mm)/(inch)
Y
(mm)/(inch)
E
(mm)/(inch)
Value 2.900/0.114 1.100/0.043 0.800/0.031 0.900/0.035 0.950/0.037
