AS431I
A Product Line of
Diodes Incorporated
Package Outline Dimensions
(All dimensions in mm(inch).)
(1) Package Type: TO-92 (Bulk Packing)
2.420(0. 095)
2.660(0.105)
0.360(0. 014)
0.760(0. 030)
Φ1.600(0. 063)
MAX
1
2
.5
0
0
(0
.4
9
2
)
1
5
.5
0
0
(0
.6
1
0
)
1.270(0. 050)
TYP
3
.3
0
0
(0
.1
3
0
)
3
.7
0
0
(0
.1
4
6
)
4
.3
0
0
(0
.1
6
9
)
4
.7
0
0
(0
.1
8
5
)
1.000(0. 039)
1.400(0. 055)
4.400(0. 173)
4.800(0. 189)
3.430(0. 135)
MIN
0.320(0. 013)
0.510(0. 020)
0. 000(0. 000)
0. 380(0. 015)
