Absolute Maximum Ratings (Note 1)
Symbol Parameter Rating Unit
V
IN
Input Voltage 36 V
T
J
Operating Junction Temperature 150 ºC
T
LEAD
Lead Temperature (Soldering, 10sec) 260 ºC
P
D
Power Dissipation 750 mW
T
STG
Storage Temperature Range -65 to 150 ºC

JA
Thermal Resistance TO-92 180 ºC/W
ESD ESD (Human Body Model) 2000 V
ESD ESD (Machine Model) 200 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress
ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating
Conditions” is not implied. Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
IN
Input Voltage
AS78L05 30
V AS78L12 36
AS78L15 36
T
J
Operating Junction Temperature Range -40 125 ºC
