Electrical Characteristics (Cont.)
AZV331-5V DC Electrical Characteristics (Limits in standard typeface are guaranteed for T
A
=25ºC, V
CC
=5V, V
EE
=0V,
R
L
=5.1kΩ connected to V
CC
and V
CM
=0, bold typeface applies over full temperature ranges, unless otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
V
OS
Input Offset Voltage
1.7 7
mV
9
TCV
OS
Input Offset Voltage Average
Drift
5 µV/ºC
I
B
Input Bias Current
I
IN
+ or I
IN
- with output in
linear range, V
CM
=0V
25 250
nA
400
I
IO
Input Offset Current I
IN
+ - I
IN
-, V
CM
=0V
2 50
nA
150
V
SAT
Saturation Voltage I
SINK
≤4mA
200 400
mV
500
I
SINK
Output Sink Current V
O
≤1.5V 10 84 mA
V
CM
Input Common-Mode Voltage
Range
-0.1 4.2 V
A
V
Voltage Gain 20 50 V/mV
I
CC
Supply Current
60 120
µA
150
I
LEAKAGE
Output Leakage Current 0.003 µA
AZV331-5V AC Electrical Characteristics (All limits are guaranteed for T
A
=25ºC, V
CC
=5V, V
EE
=0V, R
L
=5.1kΩ connected to
V
CC
and V
CM
=0, unless otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
T
PHL
Propagation Delay (High to Low)
Input Overdrive=10mV 600
ns
Input Overdrive=100mV 200
T
PLH
Propagation Delay (Low to High)
Input Overdrive=10mV 450
ns
Input Overdrive=100mV 300
