Electrical Characteristics
AZV331-2.7V DC Electrical Characteristics
(Limits in standard typeface are guaranteed for T
A
=25ºC, V
CC
=2.7V, V
EE
=0V,
R
L
=5.1kΩ connected to V
CC
and V
CM
=0, bold typeface applies over full temperature ranges, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Typ
Max
Unit
V
OS
Input Offset Voltage
1.7 7
mV
9
TCV
OS
Input Offset Voltage Average
Drift
5
µV/ºC
I
B
Input Bias Current
I
IN
+ or I
IN
- with output in
linear range, V
CM
=0V
10
250
nA
400
I
IO
Input Offset Current
I
IN
+ - I
IN
-, V
CM
=0V
5
50
nA
150
V
SAT
Saturation
Voltage
I
SINK
≤1mA
200
mV
500
I
SINK
Output Sink Current
V
O
≤1.5V 5
23
mA
V
CM
Input Common-Mode Voltage
Range
-0.1
2
V
I
CC
Supply Current
40
100
µA
150
I
LEAKAGE
Output Leakage Current
0.003
µA
AZV331-2.7V AC Electrical Characteristics
(All limits are guaranteed for T
A
=25ºC, V
CC
=2.7V, V
EE
=0V, R
L
=5.1kΩ
connected to V
CC
and V
CM
=0, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Typ
Max
Unit
T
PHL
Propagation Delay (High to Low)
Input
Overdrive=10mV
1000
ns
Input Overdrive=100mV
350
T
PLH
Propagation Delay (Low to High)
Input Overdrive=10mV
500
ns
Input Overdrive=100mV
400
