2
Jan. 2013 Rev. 1. 7 BCD Semiconductor Manufacturing Limited
Data Sheet
DUAL BIPOLAR OPERATIONAL AMPLIFIERS AZ4558C
Functional Block Diagram
Figure 3. Functional Block Diagram of AZ4558C (Each Amplifier)
Figure 2. Pin Configuration of AZ4558C (Top View)
(SOIC-8)
V
CC
OUTPUT 2
INPUT 2-
INPUT 2+
OUTPUT 1
INPUT 1-
INPUT 1+
V
EE
Pin Configuration
M Package
- Input
+ Input
V
EE
Output
V
CC
(DIP-8)
P Package
V
CC
OUTPUT 2
INPUT 2-
INPUT 2+
OUTPUT 1
INPUT 1-
INPUT 1+
V
EE
1
2
3
4
8
7
6
5
1
2
3
4
8
7
6
5
