AZV393
A Product Line of
Diodes Incorporated
AZV393
Document number: DS36552 Rev. 1 - 4
4 of 16
www.diodes.com
September 2013
© Diodes Incorporated
2.7V AC Electrical Characteristics (@T
A
= +25°C, V
CC
= 2.7V, V
EE
= 0V, R
L
= 5.1kΩ connected to V
CC
and V
CM
= 0, unless
otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
T
PHL
Propagation Delay (High to Low)
Input Overdrive = 10mV – 1000 –
ns
Input Overdrive = 100mV – 350 –
T
PLH
Propagation Delay (Low to High)
Input Overdrive = 10mV – 500 –
ns
Input Overdrive = 100mV – 400 –
5V DC Electrical Characteristics (@T
A
= +25°C, V
CC
= 5V, V
EE
= 0V, R
L
= 5.1kΩ connected to V
CC
and V
CM
= 0, bold typeface
applies over full temperature ranges, unless otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
V
OS
Input Offset Voltage
– – 1.7 7
mV
– – – 9
TCV
OS
Input Offset Voltage Average Drift – – 5 – μV/°C
I
B
Input Bias Current
I
IN
+ or I
IN
- with output in
linear range, V
CM
=0V
– 25 250
nA
– – 400
I
IO
Input Offset Current I
IN
+ - I
IN
-, V
CM
=0V
– 2 50
nA
– – 150
V
SAT
Saturation Voltage I
SINK
≤4mA
– 200 400
mV
– – 500
I
SINK
Output Sink Current V
O
≤1.5V 10 84 – mA
V
CM
Input Common Mode Voltage Range – -0.1 – 4.2 V
A
V
Voltage Gain – 20 50 – V/mV
I
CC
Supply Current –
– 100 200
μA
– – 250
I
LEAKAGE
Output Leakage Current – – 0.003 – μA
5V AC Electrical Characteristics (@T
A
= +25°C, V
CC
= 5V, V
EE
= 0V, R
L
= 5.1kΩ connected to V
CC
and V
CM
= 0, unless
otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
T
PHL
Propagation Delay (High to Low)
Input Overdrive=10mV – 600 –
ns
Input Overdrive=100mV – 200 –
T
PLH
Propagation Delay (Low to High)
Input Overdrive=10mV – 450 –
ns
Input Overdrive=100mV – 300 –
