Absolute Maximum Ratings (Note 1)
Symbol Parameter Rating Unit
V
CC
Power Supply Voltage 6 V
T
J
Operation Junction Temperature +150 °C
T
STG
Storage Temperature Range -65 to +150 °C
T
LEAD
Lead Temperature (Soldering, 10 seconds) +260 °C
– ESD (Machine Model) 300 V
– ESD (Human Body Model) 4000 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
CC
Supply Voltage 2.5 5.5 V
T
A
Ambient Operating Temperature Range -40 +85 °C
2.7V DC Electrical Characteristics (@T
A
= +25°C, V
CC
= 2.7V, V
EE
= 0V, R
L
= 5.1kΩ connected to V
CC
and V
CM
= 0, bold
typeface applies over full temperature ranges, unless otherwise specified.)
Symbol Parameter Conditions Min Typ Max Unit
V
OS
Input Offset Voltage
– – 1.7 7
mV
– – – 9
TCV
OS
Input Offset Voltage Average Drift – – 5 – μV/°C
I
B
Input Bias Current
I
IN
+ or I
IN
- with output in
linear range, V
CM
= 0V
– 10 250
nA
– – 400
I
IO
Input Offset Current I
IN
+ - I
IN
-, V
CM
= 0V
– 5 50
nA
– – 150
V
SAT
Saturation Voltage I
SINK
≤ 1mA
– 200 –
mV
– – 500
I
SINK
Output Sink Current V
O
≤ 1.5V 5 23 – mA
V
CM
Input Common Mode Voltage Range – -0.1 – 2 V
I
CC
Supply Current –
– 70 150
μA
– – 200
I
LEAKAGE
Output Leakage Current – – 0.003 – μA
