LOW POWER LOW OFFSET VOLTAGE SINGLE COMPARATOR AS331
Data Sheet
8
May. 2010 Rev. 1. 4 BCD Semiconductor Manufacturing Limited
Typical Performance Characteristics (Continued)
Figure 17. Response Time for Negative Transition Figure 16. Response Time for Positive Transition
Figure 19. 100kHz Response Figure 18. 100kHz Response
V
CC
=15V
V
CC
=5V
Input
Output
Input Overdrive Voltage=100mV
V
CC
=15V
V
CC
=5V
Input
Output
Output
Input Overdrive Voltage=100mV
Input
Output
V
CC
=5V, R
L
=5.1K Ω
Input Overdrive Voltage=100mV
Input
Output
Input Overdrive Voltage=5mV
V
CC
=5V, R
L
=5.1K Ω
