Data Sheet
High Sensitivity Micropower Omnipolar Hall-Effect Switch AH9248
Jul. 2011 Rev. 1. 6 BCD Semiconductor Manufacturing Limited
5
Absolute Maximum Ratings (T
A
=25
°C, Note 1)
Parameter Symbol Value Unit
Supply Voltage V
CC
7 V
Supply Current (Fault) I
CC
6 mA
Output Voltage V
OUT
7 V
Output Current I
OUT
2 mA
Magnetic Flux Density B Unlimited Gauss
TO-92S-3 400
SOT-23-3 230
Power Dissipation P
D
DFN-2×2-3 230
mW
Storage Temperature T
STG
-55 to 150
°C
Junction Temperature T
J
150
°C
ESD (Machine Model) (Note 2) ESD 200 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Note 2: Electronic semiconductor products are sensitive to Electro Static Discharge (ESD). Always observe
Electro Static Discharge control procedures whenever handling semiconductor products.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Supply Voltage V
CC
2.5 5.5 V
Operating Temperature T
OP
-40 85
°C
