AH1892
PROGRAMMABLE MICROPOWER OMNIPOLAR
HALL-EFFECT SENSOR SWITCH
AH1892
Document number: DS35092 Rev. 1 - 2
8 of 11
www.diodes.com
May 2012
© Diodes Incorporated
NEW PROD
UC
T
Ordering Information
Device Package Code
Packaging
(Note 11)
7” Tape and Reel
Quantity Part Number Suffix
AH1892-CD4-7 CD4 U-WLB0707-4 3000/Tape & Reel -7
AH1892-Z-7 Z SOT553 3000/Tape & Reel -7
Notes: 11. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
Marking Information
(1) Package type: U-WLB0707-4
Part Number Package Identification Code
AH1892-CD4-7 U-WLB0707-4 B2
(2)
Package type: SOT553
Part Number Package Identification Code
AH1892-Z-7 SOT553 B2
