AH1884
MICROPOWER, ULTRA-SENSITIVE HALL EFFECT
SWITCH
AH1884
Document number: DS31171 Rev. 6 - 2
6 of 7
www.diodes.com
September 2010
© Diodes Incorporated
Marking Information
(1) SOT553
( Top View )
Y : Year : 0~9
X : A~Z : Green
XX : Identification Code
W : Week : A~Z : 1~26 week;
a~z : 27~52 week;
z represents 52 and 53 week
XX Y W X
Part Number Package Identification Code
AH1884 SOT553 KR
Package Outline Dimensions (All Dimensions in mm)
(1) Package Type: SOT553
1.0Typ.
0.15/0.30(5x)
0.
30
C
0.10 M C A-B D
B
1.
10
/1
.2
5
C L
CL
1.
55
/1
.7
0
D
0.
30
C
D
6°
~8
°
0.10/0.18
0.
55
/0
.6
2
1.50/1.70
0.30 C D
A
6°~8°
6°~
8°
Top View
1.2
5x
-0
.5
Land Pattern Recommendation
(Unit:mm)
1.0Typ.
1.7 2.
2
Pin1
Pin1
0.1
C L
CL
0.5Typ.
0.5Typ. 0.3
0.32/0.58
0.
45
/0
.6
7
Hall Sensor
