ATS137
SINGLE HALL EFFECT SWITCH
ATS137 Rev. 10
2 of 12
FEBRUARY 2010
DS31045
©
Diodes Incorporated
ATS 137 - X X - X - X
Packing
7 : Tape & Reel
B : Bulk (Note 4)
A : Ammo Box (Note 3)
P : SIP-3L
W : SC59-3L
Package
Lead Free
L : Lead Free
Magnetic
Characteristics
A or B (Note 5)
G : Green
Device
Package
Code
Packaging
(Note 2)
Bulk
7” Tape and Reel
Ammo Box
Magnetic
Characteristics
(Note 5)
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
ATS137-PL-A-A P SIP-3L NA
NA
NA
NA 4000/Box -A
A
ATS137-PL-A-B P SIP-3L NA
NA
NA
NA 4000/Box -A
B
ATS137-PL-B-A P SIP-3L 1000 -B
NA
NA
NA
NA
A
ATS137-PL-B-B P SIP-3L 1000 -B
NA
NA
NA
NA
B
ATS137-PG-A-A P SIP-3L NA
NA
NA
NA 4000/Box -A
A
ATS137-PG-A-B P SIP-3L NA
NA
NA
NA 4000/Box -A
B
ATS137-PG-B-A P SIP-3L 1000
-B
NA
NA
NA
NA
A
ATS137-PG-B-B P SIP-3L 1000
-B
NA
NA
NA
NA
B
ATS137-WL-7-A
W
SC59-3L
NA NA
3000/Tape
&
Reel
-7 NA NA
A
ATS137-WG-7-A
W
SC59-3L
NA NA
3000/Tape
&
Reel
-7 NA NA
A
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
3. Ammo Box is for SIP-3L Spread Lead.
4. Bulk is for SIP-3L Straight Lead.
5. Please refer the Magnetic Characteristics table, B is available in SIP-3L package only.
(1) SIP-3L
(2) SC59-3L
( Top View )
1. Vcc
2. GND
3. DO
1. Vcc
GND 2.
3. DO
( Top View )
Ordering Information
Pin Assignment
