AH3360
Document number: DS35744 Rev. 1 - 2
4 of 11
August 2013
© Diodes Incorporated
NEW PROD
UC
T
AH3360
Magnetic Characteristics
(Note 9 &10) (T
A
= 25°C, V
DD
= 1.85V, unless otherwise specified)
(1mT=10 Gauss)
Symbol Characteristics
Test
Condition
Min
Typ
Max
Unit
Bops (south pole to part marking side)
Operation Point
T
A
= +25°C
16
30
42
Gauss
T
A
= -40°C to +85°C
14
30
46
Brps (south pole to part marking side)
Release Point
T
A
= +25°C
11
20
35
T
A
= -40°C to +85°C
9
20
39
Bhy (|Bopx|-|Brpx|)
Hysteresis (Note 11)
T
A
= +25°C
5
10
15
T
A
= -40°C to +85°C
3
10
17
Notes:
9. Typical data is at T
A
= +25
C, V
DD
= 1.85V.
10. Maximum and minimum parameters values over operating temperature range are not tested in production, they are guaranteed by design, process
control and characterization. The magnetic characteristics may vary with supply voltage, operating temperature and after soldering.
11. Maximum and minimum hysteresis is guaranteed by design and characterization.
