Data Sheet
BIPOLAR HALL-EFFECT POSITION SENSORS AH41
Nov 2010 Rev. 1. 2 BCD Semiconductor Manufacturing Limited
4
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Supply Voltage V
CC
-24 to 28 V
Output OFF Voltage V
CE
30 V
Output Sink Current (Continuous Current) I
OUT
50 mA
Power Dissipation (T
A
=25
°C)
P
D
400 mW
Storage Temperature T
STG
-65 to 150
°C
Junction Temperature T
J
150
°C
ESD (Machine Model) 300 V
ESD (Human Body Model) 2000 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions (T
A
=25
°C)
Parameter Symbol Min Max Unit
Supply Voltage V
CC
4 24 V
Operating Temperature T
OP
-40 150
°C
