AH342
Operation Characteristics
Performance Characteristics
T
A
( °C) 25 50 60 70 80 85 90 95 100
P
D
(mW) 550 440 396 352 308 286 264 242 220
T
A
( °C) 105 110 115 120 125 130 135 140 150
P
D
(mW) 198 176 154 132 110 88 66 44 0
Marking Side
S
B
hy
V
SAT
V
CC
V
d
B
rp
B
op 0 S
N
(Magnetic Flux Density )
DO
High
Low
(SIP-4L)
N
(Output Voltage)
