ADJUSTABLE-SPEED SINGLE-PHASE FULL-WAVE PRE-DRIVER FOR MOTOR AM4967
Data Sheet
6
Oct. 2008 Rev. 1. 2
BCD Semiconductor Manufacturing Limited
Parameter Symbol
Value
Unit
Supply Voltage
V
CC
18
V
OUT1B/OUT2B Output Current
I
OUTB
20
mA
OUT1/OUT2 Sink Current
I
OUT
20
mA
OUT1B/OUT2B/OUT1/OUT2
Withstand Voltage
V
OUT
18
V
VPWM/VMIN Withstand Voltage
V
PWM
/V
VMIN
7
V
LS Withstand Voltage
V
LS
7
V
FG/RD Withstand Voltage
V
FG
/V
RD
V
CC
V
FG/RD Output Current
I
FG
/I
RD
10
mA
VREF Output Current
I
REF
20
mA
Power Dissipation
(Note 2)
P
D
800
mW
Storage Temperature Range
T
STG
-55 to 150
o
C
ESD (Human Body Model)
ESD
2000
V
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
Note 2: When mounted on the specified printed circuit board (114.3mm
×
76.1mm
×
1.6mm, glass epoxy).
Parameter
Symbol
Min
Typ
Max
Unit
Supply Voltage
V
CC
5.5
16
V
VPWM/VMIN Input Voltage
0
5
V
Hall Input Voltage
0.2
3
V
Ambient Temperature
T
A
-30
105
o
C
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
