Preliminary Datasheet
1.6x Linear DC Fan Driver with VOUT Fully on Control AP2113
Mar. 2012 Rev 1. 3 BCD Semiconductor Manufacturing Limited
5
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Input Voltage V
IN
6.0 V
VSET Input Voltage V
SET
5.5 V
FON
________
Input Voltage 5.5 V
Operating Junction Temperature
Range
T
J
150 ºC
Storage Temperature Range T
STG
-65 to 150 ºC
Thermal Resistance （Junction to
Ambient）(No Heat Sink)
θ
JA
SOIC-8 144 °C/W
ESD (Machine Model) 300 V
ESD (Human Body Model) 6000 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Input Voltage V
IN
2.5 5.5 V
Operating Ambient Temperature
Range
T
A
-40 85 °C
