AH291
LOW VOLTAGE HALL-EFFECT SMART FAN MOTOR
CONTROLLER
AH291
Document number: DS31041 Rev. 8 - 2
6 of 9
www.diodes.com
June 2010
© Diodes Incorporated
Ordering Information
AH 291 - X G - X
Packing
B : Bulk P : SIP-4L
Package Green
Y : SOT89-5L 13 : Tape & Reel
G : Green (Note 4)
Device
Package
Code
Packaging
(Note 5, 6)
Bulk 13” Tape and Reel
Quantity
Part Number
Suffix
Quantity
Part Number
Suffix
AH291-YG-13 Y SOT89-5L NA NA 2500/Tape & Reel -13
Notes: 4. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
http://www.diodes.com/products/lead_free.html.
5. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
6. Reverse taping as shown on Diodes Inc. Surface Mount (SMD) Packaging document AP02007, which can be found on our website
http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
(1) SIP-4L
291 Part Number
( Top View )
Y WW X
X : Internal Code : A~Z : Green
Y : Year : 0~9
WW : Week : 01~52, " 52" represents
52 and 53 week
(2) SOT89-5L
1 2 3
5
7
4
291 Y W X
( Top View )
Y : Year : 0~9
W : Week : A~Z : 1~26 week;
X : Internal code
a~z : 27~52 week;
z represents 52 and 53 week
A~Z : Green
