Page 3: Vdd dob do
AH287
HIGH VOLTAGE HALL-EFFECT SMART FAN MOTOR
CONTROLLER
AH287 Rev. 10
3 of 11
APRIL 2010
DS31042
©
Diodes Incorporated
Pin Name
Description
Vdd Input
Power
DO Output
Pin
DOB Output
Pin
GND Ground
NC Not
Connected
Block Diagram
Hall
Plate
Control Logic
Regulator
Lock Shutdown
and
Automatic Recovery
Vdd
DOB
DO
Amp.
GND
Pin Descriptions
