EIGHT-CHANNEL CONSTANT CURRENT SINK WITH CURRENT MATCH AP3608E
Data Sheet
2
Mar. 2011 Rev. 1. 5 BCD Semiconductor Manufacturing Limited
Figure 2. Pin Configuration of AP3608E (Top View)
Pin Configuration
(QFN-4 × 4-24)
FN Package
Pin 1 Dot by Marking
1
2
3
4
5
6
7 8 9 10 11 12
13
14
15
16
17
18
19 20 21 22 24 23
CH1
CH2 CH3 CH4 CH5 CH6
CH7
CH8 NC
NC
NC
PWM
NC
ISET FB SDB
AGND
NC
VCC
EN
NC
SDBX FBX
PGND
Exposed
Pad
(TSSOP-20(EDP)/SOIC-20)
G/M Package
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
CH1
CH2
CH3
CH4
PGND
PGND
CH5
CH6
CH7
CH8
EN
VCC
AGND
SDBX
SDB
FB
ISET
FBX
NC
PWM
Note: AGND must be quiet and directly connected to total C
IN
