AP5725
WHITE LED STEP-UP CONVERTER
AP5725
Document number: DS31844 Rev. 3 - 2
3 of 17
www.diodes.com
July 2010
© Diodes Incorporated
Absolute Maximum Ratings
Symbol Parameter Rating Unit
V
IN
VIN Pin Voltage -0.3~7 V
VSW SW Voltage -0.3~34 V
V
OVP
OVP Pin Voltage -0.3~35 V
V
FB
Feedback Pin Voltage -0.3~7 V
EN EN -0.3~7 V
T
J(MAX)
Maximum Junction Temperature 150
o
C
T
LEAD
Lead Temperature 300
o
C
T
ST
Storage Temperature Range -65 to +150
o
C
Caution: Operation above the absolute maximum ratings can cause device failure. These values, therefore, must not be exceeded under
any condition. Operation at the absolute maximum rating for extended periods, may reduce device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
IN
Input Voltage 2.7 5.5 V
T
J
Operating Junction Temperature -40 125
o
C
T
A
Operating Ambient Temperature -40 85 o C
