AP3156
HIGH EFFICIENCY 1X/1.5X/2X CHARGE PUMP
FOR WHITE LED APPLICATIONS
AP3156 Rev. 1 2 of 15 SEPTEMBER 2009
www.diodes.com © Diodes Incorporated
Package Packing Lead Free
7 : Tape & Reel G : Green
AP 3156 FV G - 7
FV : QFN4040-16
Device
Package
Code
Packaging
(Note 2)
7” Tape and Reel
Quantity Part Number Suffix
AP3156FVG-7 FV QFN4040-16 1500/Tape & Reel -7
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
http://www.diodes.com/products/lead_free.html
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
V
IN
C2
P
D1
GND
4
3
2
1
10
11
12
9
SDI
D6
Exposed
Pad
8 7 6 5
13 14 15 16
NC
V
OUT
C1
P
C1
N
C2
N
GND
D5 D3 D2
(Top View)
D4
QFN4040-16
Ordering Information
Pin Assignments
