AP1684
Document number: DS36547 Rev.
3 - 2
3 of 13
February 2014
© Diodes Incorporated
AP1684
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified. Note 4)
Symbol
Parameter
Rating
Unit
V
CC
Power Supply Voltage
-0.3 to 35
V
I
OUT
Driver Output Current
150
mA
V
CS
Voltage at CS to GND
-0.3 to +7
V
V
FB
FB Input Voltage
-40 to +10
V
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
T
LEAD
Lead Temperature (Soldering, 10 sec)
+300
°C
P
D
Power Dissipation (T
A
= +50°C)
0.65
W
JA
Thermal Resistance (Junction to Ambient)
160
°C/W
–
ESD (Human Body Model)
2000
V
–
ESD (Charged-device Model)
±1000
V
Note 4
: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to
“Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
CC
Power Supply Voltage
7
25
V
T
A
Ambient Temperature
-40
+105
°C
