1A ULTRA LOW DROPOUT LINEAR REGULATOR AZ2940
Data Sheet
5
Sept. 2011 Rev. 2. 4 BCD Semiconductor Manufacturing Limited
Parameter Symbol Min Max Unit
Input Voltage V
IN
2.5 13.2 V
Operating Junction Temperature T
J
-40 125 o
C
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Max-
imum Ratings" for extended periods may affect device reliability.
Parameter Symbol Value Unit
Input Voltage V
IN
16 V
Operating Junction Temperature T
J
150 o C
Storage Temperature Range T
STG
-65 to 150 o C
Lead Temperature (Soldering, 10sec) T
LEAD
260 o C
Thermal Resistance
θ
JA
TO-220-3 60
o
C/W
TO-263-3 60
TO-252-2 (1)/TO-252-2 (3) 100
SOT-223 120
ESD (Human Body Model) ESD 5000 V
ESD (Machine Model) ESD 300 V
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
