1A ULTRA LOW DROPOUT LINEAR REGULATOR AZ2940
Data Sheet
4
Sept. 2011 Rev. 2. 4 BCD Semiconductor Manufacturing Limited
BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant. Products with
"G1" suffix are available in green packages.
Package
Temperature
Range
Part Number Marking ID
Packing
Type
Lead Free Green Lead Free Green
TO-220-3 -40 to 125 o C
AZ2940T-3.3E1 AZ2940T-3.3G1 AZ2940T-3.3E1 AZ2940T-3.3G1 Tube
AZ2940T-5.0E1 AZ2940T-5.0G1 AZ2940T-5.0E1 AZ2940T-5.0G1 Tube
TO-263-3
AZ2940S-3.3E1 AZ2940S-3.3G1 AZ2940S-3.3E1 AZ2940S-3.3G1 Tube
AZ2940S-3.3TRE1 AZ2940S-3.3TRG1 AZ2940S-3.3E1 AZ2940S-3.3G1 Tape & Reel
AZ2940S-5.0E1 AZ2940S-5.0G1 AZ2940S-5.0E1 AZ2940S-5.0G1 Tube
AZ2940S-5.0TRE1 AZ2940S-5.0TRG1 AZ2940S-5.0E1 AZ2940S-5.0G1 Tape & Reel
TO-252-2 (1)
/TO-252-2 (3)
-40 to 125 o C
AZ2940D-1.2G1 AZ2940D-1.2G1 Tube
AZ2940D-1.2TRG1 AZ2940D-1.2G1 Tape & Reel
AZ2940D-1.8E1 AZ2940D-1.8G1 AZ2940D-1.8E1 AZ2940D-1.8G1 Tube
AZ2940D-1.8TRE1 AZ2940D-1.8TRG1 AZ2940D-1.8E1 AZ2940D-1.8G1 Tape & Reel
AZ2940D-2.5E1 AZ2940D-2.5G1 AZ2940D-2.5E1 AZ2940D-2.5G1 Tube
AZ2940D-2.5TRE1 AZ2940D-2.5TRG1 AZ2940D-2.5E1 AZ2940D-2.5G1 Tape & Reel
AZ2940D-3.3E1 AZ2940D-3.3G1 AZ2940D-3.3E1 AZ2940D-3.3G1 Tube
AZ2940D-3.3TRE1 AZ2940D-3.3TRG1 AZ2940D-3.3E1 AZ2940D-3.3G1 Tape & Reel
AZ2940D-5.0E1 AZ2940D-5.0G1 AZ2940D-5.0E1 AZ2940D-5.0G1 Tube
AZ2940D-5.0TRE1 AZ2940D-5.0TRG1 AZ2940D-5.0E1 AZ2940D-5.0G1 Tape & Reel
SOT-223 -40 to 125 o C
AZ2940H-1.2TRG1 GH12B Tape & Reel
AZ2940H-1.8TRG1 GH12F Tape & Reel
AZ2940H-2.5TRG1 GH12G Tape & Reel
AZ2940H-3.3TRG1 GH12H Tape & Reel
AZ2940H-5.0TRG1 GH12J Tape & Reel
Package
Circuit Type
T: TO-220-3
AZ2940
S: TO-263-3
-
3.3: Fixed Output 3.3V
E1: Lead Free
TR: Tape and Reel
Blank: Tube
5.0: Fixed Output 5.0V
D: TO-252-2 (1)/TO-252-2 (3) 2.5: Fixed Output 2.5V
Ordering Information
-40 to 125 o C
1.8: Fixed Output 1.8V
G1: Green
H: SOT-223
1.2: Fixed Output 1.2V
