13

BCD Semiconductor Manufacturing Limited

Data sheet

1.5A ULTRA LOW DROPOUT LINEAR REGULATOR AZ39151

Dec. 2011 Rev. 1. 9

Mechanical Dimensions

TO-252-5

Unit: mm(inch)

6.350(0.250)

6.650(0.262)

5.200(0.205)

5.400(0.213)

9.500(0.374)

9.900(0.390)

1.270(0.050)

TYP

2.540(0.100)

TYP

0.400(0.016)
0.600(0.024)

5.400(0.213)
5.700(0.224)

2.550(0.100)
2.900(0.114)

0.430(0.017)
0.580(0.023)

0.000(0.000)
0.127(0.005)

0.430(0.017)
0.580(0.023)

2.200(0.087)
2.400(0.094)

3.800(0.150)

REF

1.400(0.055)
1.780(0.070)
